30-FT. HYBRID-ELECTRIC TUG YACHT

x Rebecca Cornell
30-Ft. Hybrid-Electric Tug Yacht
A two-person, great-loop cruiser
- Cruise all day, from port to port, under 100% electric power
- Charge up overnight
- 680 nautical mile range under diesel for long hops

LOA: 29 ft. - 9 in. (9.1 m)
Length Waterline: 28 ft. - 5 in. (8.7 m)
Beam Overall: 9 ft. - 8 in. (2.9 m)
Waterline Beam: 9 ft. - 7 in. (2.9 m)
Draft Max: 37 in. (94 cm)
Displacement: 17,500 lb. (7940 kg)
Diesel: 108 gal. (410 l)
Water: 90 gal. (340 l)
Engine: Beta 50 Diesel, 45 HP @ 2,800 RPM
Fischer Panda Parallel-Hybrid 48-volt, 10 KW electric motor (13.4 hp)
Batteries: (12) 8D Lithium Ion
Top Speed: 7.4 knots
Cruising Speed: 6.5 knots
Range @ Cruise Speed: 680 n. miles
Cruise Speed Electric: 5 knots
Range in Electric Motor Only: 60 n. miles
Loiter Speed: 15 knots - Range 710 n. miles
