Quicksilver
A 57-foot (17.4 m), 100%/100% motorsailer. 12 knots under power and 12 knots under sail

LOA: 57 ft. - 0 in. (17.36 m)
LWL: 49 ft. - 6 in. (15.08 m)
Beam: 14 ft. - 9 in. (4.49 m)
Beam WL: 13 ft. - 10 in. (4.21 m)
Draft (keel up): 5 ft. - 11 in. (1.80 m)
Draft (keel down): 11 ft. - 3 in. (3.43 m)
Displacement: 19.2 tons
Ballast: 8.5 tons
Sail Area: 1,583 sq. ft. (147 sq.m)
Main: 901 sq. ft. (83.7 sq.m)
Fore Triangle: 682 sq. ft. (63.3 sq.m)
SA/Disp: 20.6
Disp/WL: 158
Beam/WL: 3.57:1
Ballast/Displacement: 44%
Power: Lehman Super 275 HP Diesel

QUICKSILVER
